WE OFFER THE FOLLOWING FOR YOUR CONSIDERATION:
INVENTORY #: 11993
SERIAL #: 4411 1401H
YEAR BUILT: 1970’S
SPECIFICATIONS
SWING OVER BED 19-1/4″
SWING OVER CROSS SLIDE 10-1/4″
DISTANCE BETWEEN CENTERS 60″
SPINDLE BORE 2-1/8″
SPINDLE NOSE D1-6 CAMLOCK
SPINDLE SPEEDS 19 TO 1,500 RPM (16)
THREADS – INCH 4 TO 28 TPI
METRIC 1 – 7 MM
FEEDRATES .002 TO .0276″/REV
TAILSTOCK QUILL #4 MT
QUILL TRAVEL 6″
MAIN DRIVE MOTOR 10 HP
EQUIPPED WITH:
COOLANT SYSTEM
THREADING DIAL
CARRIAGE STOP
NEW 10″ 3 JAW CHUCK & 12″ 4 JAW CHUCK
FACEPLATE / SAFETY CHUCK COVER
More Specs Here: Wasino Wildcat
