WE OFFER THE FOLLOWING FOR YOUR CONSIDERATION:
INVENTORY #12054
SERIAL # 2D1C5H-27
YEAR BUILT: 1956 / RECONDITIONED 2015
SPECIFICATIONS:
SWING OVER WORKHEAD SLIDE 12″ (MAX)
LENGTH OF PART USING TAILSTOCK 6″ (MAX)
WHEEL DIA 4″ (MAX)
COLLET CAP 1/8 TO 1-1/4″
LEAD GENERATED W/ SPIRAL MECHANISM 1-13/16″ (MIN)
WORKHEAD SLIDE TRAVELS: LONGITUDINAL 5-3/4″
. CROSS 4-1/2″
SWIVELING: 235 DEGREE HORIZ
. 40 DEGREE VERT TILT
WHEEL SLIDE TRAVELS:
. LONGITUDINAL 6″
. CROSS 7-1/2″
. VERTICAL 8-3/4″
GRINDING WHEEL MOTOR 1/3 HP
GRINDING WHEEL SPEEDS 6,000 & 8,000 RPM
FLOOR SPACE REQUIRED: 60 X 53 X 60″ H
ELECTRICS: 220/440/3/60 WEIGHT: 1,750 LBS
LOCATION: FOB BRISTOL, CT
EQUIPPED WITH:
MISC COLLETS
STOP DOGS
WHEEL GUARD
