WE OFFER THE FOLLOWING FOR YOUR CONSIDERATION:
INVENTORY #12009
SERIAL #28929
YEAR BUILT: 1970’S
SPECIFICATIONS
GRINDING CAPACITY 10″ FLUTE LENGTH
FACE MILL DIAMETER 12″ MAXIMUM
. WHEEL SLIDE TRAVELS
. LEFT TO RIGHT 10″
. VERTICAL ADJUSTMENT 5″
. CROSS TRAVEL 6-1/4″
WORK TABLE 6-7/16″ X 10-7/8″
WORK TABLE SWIVEL 210 DEGREES
WORK TABLE ADJUSTMENT 3-1/4 X 1-1/4″
SPINDLE MOTOR 1/3 HP @ 3,450 RPM
SPINDLE SPEED 5,000 RPM
FLOOR SPACE REQUIRED 55 X 35 X 63″ HIGH
ELECTRICS: 220/440/3/60 WEIGHT: 950 LBS
LOCATION : FOB BRISTOL, CT
EQUIPPED WITH:
. STOP DOGS & WHEEL GUARD
. TOOTH REST BRACKET
. WORKHEAD ( FROM STOCK )
X-Y TABLE AND MAIN SLIDES RE-SCRAPED
ALL BINDERS IN PROPER WORKING ORDER
MACHINES OFFERED AS “FULLY RECONDITIONED & WARRANTEED”
3 MONTH SPINDLE REPLACEMENT WARRANTY
