WE OFFER THE FOLLOWING FOR YOUR CONSIDERATION:
INVENTORY # 12059
SERIAL #109
YEAR BUILT: 1970’S
SPECIFICATIONS
SPINDLE C/L TO COLUMN 36″ MAX
SPINDLE TO BASE 16″ MIN / 48″ MAX
DRILLING CAP (STEEL) 1.250″
VERTICAL ARM TRAVEL 24.5″
SPINDLE TRAVEL 7″
SPINDLE (QUILL) lDIA 2.375″
COLUMN DIA 9″
SPINDLE SPEEDS 55 TO 2200 RPM (12)
SPINDLE FEED RATES 6
SPINDLE TAPER #4MT
ARM ROTATION 360 DEGREES
EQUIPPED WITH:
SPINDLE DRIVE MOTOR 3 HP
ARM RAISING MOTOR 3/4 HP
CLAMPING MOTOR 1 HP
COOLANT MOTOR 1/8 HP
HEIGHT OF MACHINE 80″
BASE DIMENSIONS 57″ X 25″ X 6″
ELECTRICS: 220/3/60 WEIGHT: 3,000 LBS
LOCATION : FOB BRISTOL, CT
THIS MACHINE IS IN VERY CLEAN OVERALL CONDITION
NO SCORING ON COLUMN OR ARM
