WE OFFER THE FOLLOWING FOR YOUR CONSIDERATION:
INVENTORY #12074
SERIAL #E86070100H
YEAR BUILT: 1986
SPECIFICATIONS
SWING OVER BED 14.5″
SWING OVER C/S 8.25″
HOLE THRU SPINDLE 1-1/2″
SPINDLE NOSE D1-6 CAMLOCK
MAX DISTANCE BETWEEN CENTERS 32″
SPINDLE SPEEDS 55 TO 1,800 RPM (12)
CROSS SLIDE TRAVEL 7-7/8″
MOTOR DRIVE 3/5 HP 220/3/60
TAILSTOCK QUILL TAPER MT 3
TAILSTOCK QUILL TRAVEL 5-1/2″
EQUIPPED WITH:
. COOLANT SYSTEM
. FOOTBRAKE
. INCH & METRIC THREADING
. FULL LENGTH CROSS SLIDE.
. 2 SPEED MAIN MOTOR
. D1-6 FACEPLATE
