WE OFFER THE FOLLOWING FOR YOUR CONSIDERATION:
INVENTORY #12071
SERIAL #: 542-2-8979
YEAR BUILT: 1970’S
SPECIFICATIONS
TURNING DIA 3″ MAX (recommended)
TURNING LENGTH 3.5″ MAX
SPINDLE MOTOR 7.5 HP
SPINDLE SPEEDS 14 TO 2,906 RPM
TOOL TURRET 8 POSITON
TOOL TURRET HOLES 1″ DIA
DRIVESHAFT MOTOR 1/3 HP
PUMP MOTOR 1/2 HP
CROSS SLIDES TRAVEL 1-3/4″ ” MAX
EQUIPPED WITH:
4.5″ 3 JAW CUSHMAN POWER CHUCK & PNEUMATIC CONTROLS
PUSH BUTTON CONTROLS OPEN / CLOSE CHUCK
2 SPEED TRANSMISSION
BRAKE IN NEUTRAL FEATURE
- DINABRAKE
- FRONT & REAR CROSS SLIDES
- MISC B&S TOOLING
- OPERATING DOGS & SPEED & FEED CHANGE GEARS
- NO VERTICAL SLIDES – CAN BE ADDED
- VERY CLEAN – LOW HOUR CONDITION
ELECTRICS: 220/440/3/60 LOCATION: BRISTOL, CT USA (06010)
WEIGHT: 5,000 LBS
