WE OFFER THE FOLLOWING FOR YOUR CONSIDERATION:
INVENTORY #: 12021
SERIAL #: JM-10807
YEAR BUILT: 1980’S
SPECIFICATIONS
SWING OVER TABLE 10″
DISTANCE BETWEEN CENTERS 21″
TABLE WORKING SURFACE 5-5/16 X 37-1/2″
TABLE TRAVEL 16″
WHEELHEAD CROSS TRAVEL 10″
WHEELHEAD VERT TRAVEL 10″
WHEELHEAD TILTS 30 DEGREES
WHEELHEAD SWIVELS 360 DEGREES
DISTANCE, SPINDLE TO TABLE 2″ TO 12″
WHEEL SPEEDS 2600, 3700, 6200 RPM
SPINDLE DRIVE MOTOR 2 HP
FLOOR SPACE REQUIRED 51 X 62 X 48″
ELECTRICS: 220/440/3/60 WEIGHT: 2,000 LBS
LOCATION : FOB BRISTOL, CT
EQUIPPED WITH:
. WHEEL HEAD SWIVELS & TILTS
. ROLLER BEARING TABLEWAYS
. DUAL OPERATOR CONTROLS
. FOOTSTOCKS
. WORKHEAD (FROM STOCK)
ELECTRICS: 220/440/3/60 WEIGHT: 2,000 LBS
LOCATION : FOB BRISTOL, CT
