WE OFFER THE FOLLOWING FOR YOUR CONSIDERATION:
INVENTORY #: 11992
SERIAL #: 3152A015Z-27
YEAR BUILT: 1970’S
SPECIFICATIONS
CAPACITY –
SWING OVER MAIN SLIDE 12″
MAX COLLET CAP ………….. 1-1/4″
GRINDING WHEELS USED ……….. 4″ DIA
MAX. LENGTH OF WORK ……………….. 6″
WORKHEAD SLIDE TRAVEL: LONGITUDINAL ………. 5-3/4″
. CROSS ………… 5-3/4″
MAX. TURNTABLE SWIVEL ………………… 235 DEG.
WHEEL SLIDE TRAVEL: LONGITUDINAL ………… 6″
. CROSS …………. 7-1/2″
. VERTICAL MOVEMENT …………… 9″
WHEELHEAD SPINDLE SPEEDS ……. 4,000, 5,730, 8,000 RPM
WORKHEAD SPINDLE SPEED …………….. 436 RPM
EQUIPPED WITH: MISC COLLETS – BOTH RANGES
OVER ARM BAR WITH CENTER SUPPORT BRACKET
MICRO STOP DOGS
2) ROLL UP WAY COVERS
ELECTRICS…………………… 220/440*/3/60
WEIGHT …………………… 1,500 LBS.
LOCATION FOB BRISTOL, CT
