WE OFFER THE FOLLOWING FOR YOUR CONSIDERATION:
INVENTORY #: 12033
SERIAL #: 2D1C5T-24-R74
YEAR BUILT: 1967
SPECIFICATIONS
SWING OVER MAIN SLIDE 12″
DISTANCE SPINDLE TO TAILSTOCK CENTER 6″
WHEEL DIA 4″ Dia
COLLET CAP 1/8 TO 1-1/4″
WORKHEAD TRAVELS: LONGITUDINAL 5-3/4″
CROSS 2-1/4″ FROM CENTER
WORKHEAD SWIVELS 235 DEGREES HORIZ
VERTICAL SWIVELS 80 DEGREES (40 DEGREES UP/DOWN)
WHEELSLIDE TRAVELS:
VERTICAL 4-1/4″ ABOVE CENTER
4-1/2″ BELOW CENTER
CROSS 7-1/2″
LONGITUDINAL 6″
GRINDING WHEEL SPEED 6,000 / 8,000 RPM
WORKHEAD SPINDLE SPEEDS NO MOTOR AT PRESENT
SPINDLE DRIVE MOTOR 1/3 HP 220/440/3/60
WORKHEAD DRIVE MOTOR NO MOTOR AT PRESENT
ELECTRICS:220/440/3/60 WEIGHT: 1,500 LBS
LOCATION : FOB BRISTOL, CT
EQUIPPED WITH:
WHEEL GUARD
MISC COLLETS
STOP DOGS
ONE SHOT LUBE (2 SYSTEMS)
CHROME HARDENED WAYS ON THREE SLIDES
MISC TOOLING
NEW LEADSCREW INSTALLED ON WHEELSLIDE L TO R AXIS
THIS MACHINE IN VERY CLEAN CONDITION
